Allen-Bradley 20G1AND186JN0NNNNN | PowerFlex 755 AC Drive | 150HP Normal Duty | Embedded EtherNet/IP | Frame 6Overview

The Allen-Bradley 20G1AND186JN0NNNNN is a high-performance PowerFlex 755 variable frequency drive (VFD) designed for advanced motor control in industrial applications. Delivering 186A output at 480V AC, this model supports up to 150 HP for normal duty and 125 HP for heavy duty loads. It includes embedded EtherNet/IP, a common mode jumper, internal EMC filter, and precharge input, making it ideal for large-scale and networked drive systems.

• Voltage Rating: 480V AC, 3-phase

• Output Current: 186A

• Horsepower Rating:

  • 150 HP Normal Duty

  • 125 HP Heavy Duty

• Frame Size: Frame 6

• Cooling Method: Forced air cooled

• Drive Type: Open Type (IP00)

• Input Configuration: AC input with precharge circuit

• DC Terminals: Not included

• Filter: EMC filter installed

• EtherNet/IP: Embedded port for seamless integration

• Common Mode Jumper: Installed for noise suppression

• Human Interface Module (HIM): Not included

• Catalog Number: 20G1AND186JN0NNNNN

• Control Modes: V/Hz, sensorless vector, vector control with encoder

• Communication Options: EtherNet/IP embedded, optional modules for others

• Ambient Temperature: 0°C to 50°C standard

• Certifications: UL, CE, CSA, RoHS

• Programming Software: Studio 5000 / Connected Components Workbench

• Dimensions (HxWxD): Approx. 850 x 370 x 320 mm (Frame 6)
