Fiber Amplifier, Cable Type, Parent Unit, PNP

• Main Unit/Expansion Unit: Main Unit
• Control output: 1 PNP open collector 24 V; max 1 output: 100 mA or less; total 2 outputs: 100 mA or less (use alone)/20 mA or less (multiple connections); residual voltage 1 V or less
• External input: -
• Light source: Red, 4 LED elements
• APC: Selectable ON/OFF (Factory setting: OFF)
• Response time: 50 µs (HIGH SPEED) /250 µs (FINE) /500 µs (TURBO) /1 ms (SUPER) /4 ms (ULTRA) /16 ms (MEGA)

Modelo: FS-N11P

Categorías: Control industrial Electrónica

Marca: Keyence

Unidad Amplificadora
